SD Shape Tungsten Carbide Rotary Burrs 3mm 6mm 10mm 12mm Shank
| MOQ: | 10pcs |
| Price: | 1.0-3.8usd |
| Standard Packaging: | plastic box , carton box |
| Delivery Period: | 3-25 days |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Capacity: | 20000pcs per month |
SD Shape Carbide Rotary Burrs
,Tungsten Carbide Rotary Burrs 3mm
,Tungsten Carbide Rotary Burrs 6mm
Precision cutting tools for professional metalworking featuring a tapered cone with rounded end design, engineered for precision contouring and smooth finishing in complex machining operations.
- Versatile Tapered Design - Ideal for angled surfaces and intricate contours
- Extended Tool Life - Premium tungsten carbide construction (5-8X longer than HSS)
- Optimized Tooth Geometry - Available in single, double, and aluminum-specific cuts
- Precision Balanced - Vibration-free operation at high RPMs (up to 35,000)
- Custom Solutions - Special configurations available for unique applications
- Carbide Grade: K10 (YG8)/K20 (YG6X) per ISO 513 standards
- Hardness: 90-92 HRA (Rockwell A scale)
- Grain Structure: Sub-micron (0.5-0.8μm) tungsten carbide
- Cobalt Content: 6-8% for optimal toughness
Standard HSS Shank:
- Material: AISI M2 high-speed steel
- Hardness: 62-64 HRC
- Surface: Precision ground with anti-corrosion treatment
Premium Carbide Shank:
- Material: Micro-grain tungsten carbide
- Hardness: 90 HRA
- Benefits: Maximum rigidity for precision work
- 1. Material Preparation - Computer-controlled blending of WC-Co powders, isostatic pressing at 300 MPa
- 2. Sintering Process - Vacuum sintering at 1420-1480°C, liquid phase sintering for maximum density (≥14.8 g/cm³)
- 3. Precision Machining - 5-axis CNC grinding with diamond wheels, tooth geometry accuracy: ±0.015mm
- 4. Quality Assurance - 100% dimensional inspection (CMM), hardness testing, dynamic balance testing (≤0.5g/mm)
| Model No. | Shank Ø (mm) | Head Ø (mm) | Taper Angle | OAL (mm) | Tooth Type | Best For |
|---|---|---|---|---|---|---|
| SD-306 | 3.0 | 6.0 | 15° | 50 | Single-cut | Hardened Steel |
| SD-610 | 6.0 | 10.0 | 20° | 75 | Double-cut | General Steel |
| SD-1016 | 10.0 | 16.0 | 15° | 100 | Aluminum-cut | Aluminum Alloys |
| SD-1220 | 12.0 | 20.0 | 30° | 125 | Double-cut | Cast Iron |
| Tooth Type | Characteristics | Best For | Surface Finish |
|---|---|---|---|
| Single-cut | Deep, aggressive cuts | Hard materials (HRC>45) | Rough (Ra 6.3-12.5μm) |
| Double-cut | Balanced performance | General purpose steel | Medium (Ra 3.2-6.3μm) |
| Aluminum-cut | High flute clearance | Non-ferrous metals | Fine (Ra 1.6-3.2μm) |
Custom tooth configurations available for special applications.
Q: What makes SD shape different from other burr shapes?
A: The tapered design with rounded end provides better access to angled surfaces and produces smoother transitions in contouring applications.
Q: How do I select the right tooth configuration?
A: Consider your material hardness and desired finish. Our engineers can recommend optimal configurations based on your specific application.
Q: What's the maximum RPM for these burrs?
A: Standard rating is 35,000 RPM. Carbide-shank versions can operate at 50,000 RPM with proper cooling.
Q: Do you offer custom angles for specialized applications?
A: Yes, we can manufacture custom taper angles from 10° to 45° to meet specific requirements.
Q: What's your lead time for custom orders?
A: Standard configurations ship in 3-5 days. Custom tools require 10-15 days for production.
Shipping Options:
- Express: DHL/UPS (2-3 business days)
- Air Freight: 5-7 days (best for urgent orders)
- Sea Container: 20-35 days (economical for bulk)
Quality Documentation:
- Material test certificates
- Dimensional inspection reports
- RoHS compliance documentation
Ordering Flexibility:
- MOQ: 10 pieces (standard sizes)
- Sample program available
- Volume discounts for orders over 500 pieces
- German-engineered production technology
- JIS B and DIN standards compliance
- On-site metallurgical lab for QC
- Dedicated technical support team
- Competitive OEM pricing
