3mm-12mm Boron Carbide Sandblasting Nozzle B4C Sandblasting Tips
| MOQ: | 1 |
| Price: | 2-10 USD |
| Standard Packaging: | Each in a Plastic Case, Total in a Carton Box. |
| Delivery Period: | 7-30 days |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union |
| Supply Capacity: | 10000PCS/Month |
Detail Information
Place of Origin
CHINA
Brand Name
ZWEIMENTOOL
Certification
ISO
Model Number
3/5/6/7/8/10/12mm B4C Sandblasting Nozzle
Material:
Boron Carbide Or Tungsten Carbide
Nozzle Length:
35/45/55/60/80mm
Inner Diameter:
3/4/5/6/7/8/9/10/12mm
Outer Diameter:
15 Mm, 20 Mm
Customized:
Available
Service:
OEM/ODM
Highlight:
12mm Boron Carbide Sandblasting Nozzle
,3mm Boron Carbide Sandblasting Nozzle
,B4C Sandblasting Tips
Product Description
Boron Carbide Blasting Nozzle
3/5/6/7/8/10/12mm B4C Sandblasting Nozzle for Rust Removal
Product Specifications
| Attribute | Value |
|---|---|
| Material | Boron carbide or Tungsten carbide |
| Nozzle Length | 35/45/55/60/80mm |
| Inner Diameter | 3/4/5/6/7/8/9/10/12mm |
| Outer Diameter | 15 mm, 20 mm |
| Customization | Available |
| Service | OEM/ODM |
Product Description
B4C Boron Carbide Blasting Nozzle Head for Sand Blasting Machine
Material: Boron Carbide
Compatible Media: Steel shot, black alumina, white alumina, brown alumina, glass sand, silicon carbide, glass beads, plastic granules
Nozzle Shape: Venturi nozzle
Density: ≥ 2.46g/cm³
Bending Strength: ≥ 400 MPa
Performance: High corrosion resistance
Key Features
- Exceptional hardness and wear resistance with properties matching boron carbide
- Resistant to acids, alkalis, and extreme temperatures (both high and low)
- Microhardness ≥ 3500kgf/mm² with a melting point of 2450℃
- Can replace carbide, silicon carbide, silicon nitride, alumina, and zirconia components
Nozzle Structure & Dimensions
| 35mm | 45mm | 60mm | 80mm |
|---|---|---|---|
| 35mm×20mm×4mm | 45mm×20mm×4mm | 60mm×20mm×4mm | 80mm×20mm×4mm |
| 35mm×20mm×5mm | 45mm×20mm×5mm | 60mm×20mm×5mm | 80mm×20mm×5mm |
| 35mm×20mm×6mm | 45mm×20mm×6mm | 60mm×20mm×6mm | 80mm×20mm×6mm |
| 35mm×20mm×7mm | 45mm×20mm×7mm | 60mm×20mm×7mm | 80mm×20mm×7mm |
| 35mm×20mm×8mm | 45mm×20mm×8mm | 60mm×20mm×8mm | 80mm×20mm×8mm |
| 35mm×20mm×10mm | 45mm×20mm×10mm | 60mm×20mm×10mm | 80mm×20mm×10mm |
| 35mm×20mm×12mm | 45mm×20mm×12mm | 60mm×20mm×12mm | 80mm×20mm×12mm |
